Product Name: North AmericaFWJ系列1000V(35-2000A)
Product parameters and model:
voltage 1000Vcurrent35-2000A
FWJ-35A FWJ-150A FWJ-800A
FWJ-40A FWJ-175A FWJ-1000A
FWJ-50A FWJ-200A FWJ-1200A
FWJ-60A FWJ-250A FWJ-1400A
FWJ-70A FWJ-300A FWJ-1600A
FWJ-80A FWJ-350A FWJ-1800A
FWJ-90A FWJ-400A FWJ-2000A
FWJ-100A FWJ-500A
FWJ-125A FWJ-600A
The 35-600A product has been recognized by UL.
35-200: Symmetrical breaking capacity of 25KA RMS.
250A-2000A: Symmetrical breaking capacity of 100KA RMS.
The power loss is the power loss value at rated current.
800V DC/breaking capacity 50KA.
Basic introduction:
BUSSMANN offers a full range of North American knife type flat end fuses and accessories. The product design and construction have been optimized and have the following characteristics:
1. Low power integration flux (I2t)
2. Low power loss
3. High recyclability
4. Low arc voltage
5. Superior DC performance
For some North American series products, external and internal open type fuse indicators can be provided. For most applications, a fuse base can be provided.
BUSSMANN North American series fuse bases 1BS101, 1BS102, 1BS103, 1BS104.
Joint type fuse holder, suitable for wire termination and has heat dissipation function.
1BS101 has a maximum voltage of 600V and a maximum rated current of 100A.
1BS102 maximum voltage 600V, current 400A;
1BS103 maximum voltage 600V, current 400A;
1BS104 has a maximum voltage of 600V and a current of 600A.
BUSSMANN offers a variety of TRON brand fixed rectifier fuse holders.
The connection of cables and fuses is the same as that of bolt type fuse holders, and can be installed with double headed bolts.
